Specification:
Oscillation mode:-------------------------------------------------PLL synthesized
Frequency stability:--------------------------------------------------------±0.005%
Frequency range:-----------------------------------------------------798~830MHz
Frequency alternation:-------------------------------------------------------32MHz
Operate mode:--------------------------------------------------manual adjusting
Receiving way:---------------------------------------------------------single tuning
Sensitivity:---------Deviation 25KHz, when connected 7dBuV, S/N>78dB
Max Deviation:---------------------------------------------------------------±48KHz
S/N:------------------------------------------------------------------- >94dB(1KHz-A)
T.H.D.:------------------------------------------------------------------- <3% @1KHz
Frequency response:-----------------------------------------80Hz- 15KHz±3dB
Transmitter output power:-----------------------------------2 x 50mW @ 1KHz
AF output:--------------------------------------------------  Φ3.5mm Mono socket
Power supply:-------------------------------------------------------------AA 1.5V x 2
Current consumption:---------------------------------------------------3V/120mA
